Engine data
| Engine Type | 1.3i HCS Endura-E |
1.3i HCS Endura-E |
1.25i 16V Zetec-SE | 1.4i 16V Zetec-SE | 1.6i 16V Zetec-SE | |
| Displacement - cc | 1,299 | 1,299 | 1,242 | 1,388 | 1,596 | |
| Bore - mm | 73.96 | 73.96 | 71.9 | 76.0 | 79.0 | |
| Stroke - mm | 75.48 | 75.48 | 76.5 | 76.5 | 81.4 | |
| Compression ratio | 9.5:1 | 9.5:1 | 10.0:1 | 10.3:1 | 11.0:1 | |
| Fuel type, grade | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | |
| Max Power - ISO PS/kw | 50/37 | 60/44 | 75/55 | 90/66 | 105/74 | |
| At engine speed (rpm) | 4,500 | 5,000 | 5,200 | 5,500 | 6,000 | |
| Torque - ISO Nm | 94 | 103 | 110 | 125 | 145 | |
| At engine speed (rpm) | 2,500 | 2,500 | 4,000 | 4,500 | 4,000 |
Construction
| Engine Type | 1.3i HCS Endura-E | 1.3i HCS Endura-E | 1.25i 16V Zetec-SE | 1.4i 16V Zetec-SE | ||
| Displacement - cc | 1,299 | 1,299 | 1,242 | 1,388 | ||
| Bore - mm | 73.96 | 73.96 | 71.9 | 76.0 | ||
| Stroke - mm | 75.48 | 75.48 | 76.5 | 76.5 | ||
| Compression ratio | 9.5:1 | 9.5:1 | 10.0:1 | 10.3:1 | ||
| Fuel type, grade | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | Unleaded gasoline, 95 (RON) octane | ||
| Max Power - ISO PS/kw | 50/37 | 60/44 | 75/55 | 90/66 | ||
| At engine speed (rpm) | 4,500 | 5,000 | 5,200 | 5,500 | ||
| Torque - ISO Nm | 94 | 103 | 110 | 125 | ||
| At engine speed (rpm) | 2,500 | 2,500 | 4,000 | 4,500 | ||
| Cylinders | 4 in-line | 4 in-line | 4 in-line | 4 in-line | ||
| Head | Cast iron | Cast iron | Aluminium alloy | Aluminium alloy | ||
| Block | Cast iron | Cast iron | Aluminium alloy | Aluminium alloy | ||
| Main bearings | 5 | 5 | 5 | 5 | ||
| Counterweights | 4 | 4 | 8 | 8 | ||
| Valve gear | OHV | OHV | DOHC | DOHC | ||
| Camshaft drive | Chain | Chain | Belt | Belt | ||
| Engine management | Electronic with EEC-V controls | Electronic with EEC-V controls | Siemens integrated PCS | Siemens integrated PCS | ||
| Injection/air charge | Sequential Electronic Multipoint | Sequential Electronic Multipoint | Sequential Electronic Multipoint | Sequential Electronic Multipoint | ||
| Ignition | Ford electronic distributorless | Ford electronic distributorless | Ford electronic distributorless with knock sensor | Ford electronic distributorless with knock sensor | ||
| Emission controls | Closed-loop 3-way catalyst | Closed-loop 3-way catalyst | Closed-loop 3-way catalyst | Closed-loop 3-way catalyst | ||
| Level | EC Stage 2 | EC Stage 2 | EC Stage 2 | EC Stage 2 |
Manual Transmissions
| Type-Manual | Improved B5 | ||||
| Clutch type | Hydraulically-operated single plate diaphragm spring | ||||
| Diameter, mm | Gasoline 180; Diesel 210 | ||||
| Ratios | 1.3i HCS Endura-E | 1.25i 16V Zetec-SE | 1.4i 16V Zetec-SE | 1.6i 16V Zetec-SE | 1.8 NA IDI Endura-D |
| 1st | 3.58 | 3.58 | 3.58 | 3.15 | 3.58 |
| 2nd | 1.93 | 1.93 | 1.93 | 1.93 | 1.93 |
| 3rd | 1.28 | 1.28 | 1.28 | 1.28 | 1.28 |
| 4th | 0.95 | 0.95 | 0.95 | 0.95 | 0.95 |
| 5th | 0.76 | 0.76 | 0.76 | 0.76 | 0.76 |
| Reverse | 3.62 | 3.62 | 3.62 | 3.62 | 3.62 |
| Final Drive Ratio | 3.82 | 4.06 | 4.06 | 4.25 | 3.82 |
Automatic Transmission
| Type - automatic | Belt-drive/pulley continuously variable ratio with hydraulic controls |
| Clutch type | Automatic multi-plate wet type |
| Ratios: | 1.25i 16V Zetec-SE |
| Low | 3.84 |
| High | 0.66 |
| Reverse | 4.27 |
| Final Drive Ratio | 3.84 |
Body
| Structure | Computer-optimised, high efficiency, unitary-welded steel body incorporating rigid occupant protection cell and front and rear energy-absorbing crumple zones. Direct-glazed windshield. Drag coefficient 0.36. |
| Safety features | Integrated safety concept incorporating optimised reinforcement for high-energy and offset frontal impacts, side impacts and rear impacts, with door beams, facia cross-beam and steering column support. Driver's side air bag standard and passenger's side air bags available. (NOTE: Varies by market) |
| Bumper system | Damage-resistant, full-depth moulded reinforced polypropylene |
| Anti-corrosion | 24-stage paint and body protection process, optimised phosphate spray coat, electrocoat filler/surfacer, comprehensive wax injection of cavities, PVC and wax underbody coating plus stone chip protection. Particular attention paid to sealing flanges with rust-inhibiting adhesive and thick PVC sealing beads. Front plastic wheelarch liners, rear textile wheelarch liners, plastic anti-scuff strips on inner front door sills and rear load sill. |
| Suspension | |
| Front | Independent by MacPherson struts with offset coil spring/damper units and lower L-arms in optimised bushes mounted on separate cross-member. |
| Rear | Semi-independent twist-beam with strut-type coil spring/damper units. Dual path body mounts. |
| Steering | |
| Type | Variable-rate rack and pinion with power assisstance (except Budget) (NOTE: may vary by market) |
| Turning circle, m (Kerb-to-kerb) | 9.9 (Sport: TBC) |
| Brakes | |
| Type | Dual circuit, diagonally split, hydraulically-operated disc front and drum rear. Vacuum servo assisted with optional electronically -controlled four-channel brake distribution, anti-lock system. |
| Front | 239mm diameter ventilated discs (258 mm on Sport) |
| Rear | 180 x 30 mm diameter drums (200 mm on Sport) |
| Wheels and Tyres | |||||
| Budget | Ambiente | Trend | Ghia | Sport | |
| Wheel type | Pressed steel | Pressed steel | Pressed steel | Alloy | Alloy |
| Wheel size | 13 x 5 in. | 13 x 5 in. | 14 x 5.5 in. | 14 x 5.5 in | 15 x 6 in. |
| Tyre Sizes | |||||
| 1.3L Endura-E | 165/70R 13T | 165/70R 13T | NA | NA | NA |
| 1.25L Zetec-SE | NA | 165/70R 13T | 185/55R 14H | 185/55 14H | NA |
| 1.4L Zetec-SE | NA | NA | 185/55R 14H | 185/55 14H | NA |
| 1.6L Zetec-SE | NA | NA | NA | NA | 195/50R 15H |
| 1.8L Endura-IDI 60 | 165/70R 13T | 165/70R 13T | NA | 185/55 14H | NA |
| Dimensions | ||
| Exterior - mm | 3-door | 5-door |
| Overall length | 3,828 | 3,828 |
| Overall width | 1,634 | 1,634 |
| Overall height | 1,320 | 1,320 |
| Wheelbase | 2,446 | 2,446 |
| Front track | 1,429 | 1,429 |
| Rear track | 1,384 | 1,384 |
| Interior | ||
| Front - mm | ||
| Max headroom | 967 | 967 |
| Max leg room | 1,036 | 1,036 |
| Max shoulder room | 1,281 | 1,277 |
| Rear - mm | ||
| Max headroom | 928 | 928 |
| Max shoulder room | 1,348 | 1,285 |
| Stowable luggage | ||
| (VDA - litres) | ||
| 5-seat mode | 250 | 250 |
| 2-seat mode | 929 | 929 |
| Fuel tank - litres | 40 | 40 |
| Weights | ||||
| Engine/Bodystyle | Basic kerb weight - kg | |||
| 3-Door | Front | Rear | Total | |
| 1.3 Endura-E M5 | Budget | 576 | 344 | 920 |
| Ambiente | 588 | 345 | 933 | |
| 1.25 Zetec SE M5 | Ambiente | 568 | 344 | 912 |
| Trend | 573 | 349 | 922 | |
| Ghia | 593 | 352 | 945 | |
| 1.25 Zetec SE CTX | Ambiente | 592 | 350 | 941 |
| 1.4 Zetec SE | Trend | 574 | 349 | 922 |
| Ghia | 576 | 351 | 927 | |
| 1.6 Zetec SE | Sport | 614 | 362 | 976 |
| 1.8 Endura D M5 | Budget | 646 | 334 | 980 |
| Ambiente | 658 | 335 | 993 | |
| 5-Door | ||||
| 1.3 Endura-E M5 | Budget | 585 | 363 | 948 |
| Ambiente | 597 | 364 | 961 | |
| 1.25 Zetec SE M5 | Ambiente | 575 | 363 | 938 |
| Trend | 580 | 368 | 948 | |
| Ghia | 600 | 371 | 971 | |
| 1.25 Zetec SE M5 | Ambiente | 595 | 363 | 958 |
| Ghia | 620 | 371 | 991 | |
| 1.4 Zetec SE | Trend | 584 | 368 | 952 |
| Ghia | 611 | 376 | 987 | |
| 1.8 Endura D M5 | Budget | 655 | 353 | 1008 |
| Ambiente | 667 | 354 | 1021 | |
| Ghia | 693 | 362 | 1054 | |
| Performance and Fuel Economy | |||||||
| 1.3i HCS Endura-E (50PS) | 1.3i HCS Endura-E (60PS) | 1.25i 16V Zetec-SE (M5) | 1.25i 16V Zetec-SE (CTX) | 1.4i 16V Zetec-SE | 1.6i 16V Zetec-SE | 1.8 IDI Endura-D | |
| Max. speed - km/h (mph) | 143.2 (89.0) | 153 (95.1) | 166.7 (103.6) | 161.6 (100.4) | 177 (110.0) | 182 (113.1) | 115 (96.3) |
| Acceleration, sec 0-100 km/h (0-62 mph) | 20.2 | 16.4 | 13.1 | 15.9 | 11.4 | 10.2 | 17.5 |
| 50 - 100 km/h (31-62 mph) | 21.2 | 18.1 | 16.2 | NA | 15.3 | 11.7 | 18.6 |
| Economy L/100km (mpg) | |||||||
| Urban | 8.7 (32.5) | 8.7 (32.5) | 8.7 (32.5) | 9.3 (30.4) | 8.8 (32.1) | TBC | 7.9 (35.7) |
| Extended | 5.9 (47.9) | 5.9 (47.9) | 5.8 (48.7) | 5.8 (48.7) | 5.7 (49.5) | TBC | 5.0 (56.5) |
| Combined | 6.9 (40.9) | 6.9 (40.9) | 6.9 (40.9) | 7.1 (39.8) | 6.9 (40.9) | TBC | 6.1 (46.3) |
| CO2 | 161 | 161 | 161 | 167 | 161 | TBC | 161 |
